Single 12" active coaxial speaker with built-in DSP powered module. Coaxial design with 35mm voice coil neodymium tweeter and 156mm magnet/65mm voice coil woofer. Rated power: 300W. Max SPL: 121dB. 90°×90° even coverage. Birch plywood enclosure. Ideal for conferencing, performance, monitoring, and professional sound reinforcement.
China conference AV system manufacturer · OEM / ODM · CE / RoHS / FCC certified
Speaker Specifications Parameter Specification System Type Single 12" Coaxial Speaker Frequency Range 60Hz - 20kHz Frequency Response 70Hz - 18kHz (±3dB) Sensitivity 96dB SPL 1w/1m Impedance 8Ω Rated Power 300W Max SPL 121dB SPL Coverage 90° × 90° Tweeter 35mm Voice Coil, Neodymium Woofer 156mm Magnet / 65mm Voice Coil Enclosure High-Strength Birch Plywood Input Connectors 2×Neutrik® NL4MP Dimensions (H×W×D) 475mm × 462mm × 321mm Net Weight 16.5kg Powered Module Specifications Parameter Specification 8Ω Output Power 500W×100W 4Ω Output Power 700W×150W DSP Max Input Dynamic 10dBU THD <0.02% Frequency Response 20Hz - 20kHz, ±2dB Input Impedance 20k / 10k Input Sensitivity 4dBU S/N Ratio >100dB Crosstalk >70dB Damping Factor >300 Output Stage Class D Protection Short Circuit, DC Output, Over-Temperature, Overload Indicators Clip / Signal / Power Power-on Delay 3S Input Connector XLR Balanced Power Voltage 90V ~ 130VAC Module Dimensions (W×D×H) 335mm × 110mm × 60mm Module Net Weight 1.4kg
卡达斯 COUDUS Single 12" Active Coaxial Speaker (model TK-YX12FT-Y) is a Active Speaker / Powered Speaker product from 卡达斯 COUDUS, built for meeting rooms, lecture halls, command centers and education venues. Single 12" active coaxial speaker with built-in DSP powered module. Coaxial design with 35mm voice coil neodymium tweeter and 156mm magnet/65mm voice coil woofer. Rated power: 300W. Max SPL: 121dB. 90°×90° even coverage. Birch plywood enclosure. Ideal for conferencing, performance, monitoring, and professional sound reinforcement.
This single 12" active coaxial speaker features a point-source coaxial design with tweeter and woofer aligned on the same axis for precise sound imaging and phase coherence. Neodymium tweeter with 35mm voice coil and woofer with 156mm magnet/65mm voice coil deliver 300W rated power with 121dB max SPL. Frequency range: 60Hz-20kHz, response: 70Hz-18kHz (±3dB). 90°×90° even coverage for conferencing, performance, stage monitoring, and high-end sound reinforcement. Built-in DSP-powered module delivers 500W×100W at 8Ω and 700W×150W at 4Ω. Class D amplifier with over 90% efficiency and comprehensive protection (short circuit, DC output, over-temperature, overload). DSP provides precise crossover, EQ, and limiting for optimized performance. S/N ratio >100dB, crosstalk >70dB, damping factor >300. XLR balanced input, 90V~130VAC power supply. Module dimensions: 335×110×60mm, net weight: 1.4kg. Enclosure constructed from high-strength birch plywood with durable scratch-resistant paint finish and rigid metal grille. Ergonomic handles for convenient transport. Equipped with 2×Neutrik® NL4MP connectors.
The MOQ for the 卡达斯 COUDUS Single 12" Active Coaxial Speaker (model TK-YX12FT-Y) is 1 unit. For mixed-model orders, project tenders or OEM/ODM runs the MOQ is negotiable — send COUDUS your target quantity and destination market for a tailored quotation.
Yes. 卡达斯 COUDUS supports OEM/ODM on the Single 12" Active Coaxial Speaker, including logo printing, housing finish and colour, packaging artwork, multilingual manuals, and firmware/UI branding. Share your specification and we will confirm feasibility, tooling cost and sample lead time.
In-stock 卡达斯 COUDUS Active Speaker / Powered Speaker typically ships within 7–15 working days after payment. Bulk and customized orders usually take 20–30 working days depending on quantity and configuration. Exact lead time is confirmed on your proforma invoice.
Yes. 卡达斯 COUDUS provides a 12-month manufacturer warranty covering defects in materials and workmanship, plus lifetime remote technical support. Extended warranty and spare-part packages are available for project orders — the exact terms are stated in your quotation.
Yes, sample orders are supported. Testing a sample lets you verify audio performance, build quality, finish and system compatibility before committing to volume. Sample cost is normally credited against your subsequent bulk order.
卡达斯 COUDUS builds the Single 12" Active Coaxial Speaker under a documented quality-control process, and certification documents (CE, RoHS, FCC and others, where applicable) can be provided on request for your destination market. Tell us the target country and we will supply the relevant paperwork.
卡达斯 COUDUS designs the Single 12" Active Coaxial Speaker with standard professional interfaces so it integrates with common third-party DSPs, mixers, camera-tracking systems and control platforms. Send us your system diagram or existing equipment list and our engineers will confirm compatibility before you order.
Yes. 卡达斯 COUDUS supplies wiring diagrams, mounting templates and configuration guides with every Active Speaker / Powered Speaker order, and our engineers provide remote commissioning assistance by video call. On-site support and integrator training can be arranged for large projects.
